Description
Gate valve lockout device designed to secure valve handles ranging from 25 mm to 64 mm in diameter. The durable construction fully encloses the valve handle to prevent unauthorized operation during maintenance work. Suitable for industrial lockout/tagout procedures in process and utility systems.
Features
• Standard gate valve lockout designed to fully enclose valve handwheels and prevent unauthorized operation during maintenance
• Durable ABS construction provides impact resistance and reliable performance in industrial environments
• Compact design suitable for smaller gate valve handwheels
• Compatible with safety padlocks having shackle diameters up to 7 mm
• High-visibility red body improves lockout identification in process and utility systems
• Suitable for isolating gate valves as part of lockout/tagout safety procedures
Specifications
• Body Material: ABS
• Valve Type: Gate Valve
• Compatible Handwheel Diameter: 25 mm – 64 mm
• Equivalent Size Range: 1″ – 2.5″
• Hole Diameter: 19 mm
• Inner Height: 28 mm
• Compatible Padlock Shackle Diameter: Up to 7 mm
• Color: Red
Material
• ABS
